| Car Type: | ELANTRA 2.0L L4'00 | OEM: | 25310-2D010 |
|---|---|---|---|
| DPI: | 2387 | Core Size: | 375 * 648 * 16 / 26 Mm |
| Tank Size: | 46.5 / 46.5 * 671 Mm | Inlet Size: | 33mm |
| At / Mt: | At | Oil Cooler: | 19 * 370 Mm |
| Place Of Origin: | Guangzhou China ( Mainland ) | ||
| High Light: | hyundai radiator replacement,car radiators |
||
Auto 2000 - 2004 Hyundai Radiator for ELANTRA 2.0L L4'00 OEM 25310 - 2D010
Item Specifications
| Manufacturer Part Number | KJ-21017 |
| OEM | 25310 - 2D010 |
| Car Type | ELANTRA 2 . 0 L L4 2000 2001 2002 2003 2004 |
| Carton Size | 730 * 105 * 505 mm |
| Oil cooler | Φ 19 * 370 |
| Transmission | AT |
| Thickness | 16 / 26 mm |
| Core Size | 375 * 648 * 16 / 26 mm |
| Tank Size | 46.5 / 46.5 * 671 mm |
| DPI | 2387 |
| Core Material | Aluminum |
| Tank Material | Plastic |
Kinga Advatage Service
1. Professional & excellent engineer team
Kinga have our own professional & excellent engineers to develop and design products, which make sure
technological and innovative Radiators and Condensers for our customers!
2. High quality service
If you have any question, just feel free to contact us. We'd like to provide you with high quality service to meet
your special requirements.
3. Offer sample design
For any customers who send us products samples, we will design and develop better products for you!
4. Best quality
Kinga just have one quality with same high-quality raw material. We choose best raw material supperlier to
produce best and suitable products for you.
5. Competitive price
Kinga has its own big factory, who is even the biggest radiator manufacturer in China. So mwe can offer you
competitive price and have the ability of mass production!
Kinga Condenser for different cars
|
TOYOTA |
BENZ |
BMW |
VOLKSWANGEN |
CHRYSLER |
|
AUDI |
FAW |
DAEWOO |
GMC |
SUBARU |
|
FORD |
MAZDA |
HONDA |
LAND ROVER |
MITSUBISHI |
|
NISSAN |
ISUZU |
VOLVO |
HYUNDAi |
SUBARU
|
More Information
| KJ-21013-PA16 | ELANTRA/LANTRA'90-95 | PA16/AT |
| KJ-21013-PA26 | ELANTRA/LANTRA'90-95 | PA26/AT |
| KJ-21014-PA16 | ELANTRA/LANTRA'90-95 | PA16/MT |
| KJ-21014-PA26 | ELANTRA/LANTRA'90-95 | PA26/MT |
| KJ-21015-PA16 | ELANTRA/COUPLE/LANTRA'95 | PA16/AT |
| KJ-21015-PA22 | ELANTRA/COUPLE/LANTRA'95 | PA22/AT |
| KJ-21016-PA16 | ELANTRA/COUPLE/LANTRA'95 | PA16/MT |
| KJ-21016-PA22 | ELANTRA/COUPLE/LANTRA'95 | PA22/MT |
| KJ-21017-PA16 | ELANTRA 2.0L L4'00 | PA16/AT |
| KJ-21017-PA26 | ELANTRA 2.0L L4'00 | PA26/AT |
| KJ-21018-PA16 | ELANTRA 2.0L L4'00 | PA16/MT |
| KJ-21018-PA26 | ELANTRA 2.0L L4'00 | PA26/MT |
| KJ-21019-PA16 | ELANTRA/LANTRA'00 | PA16/AT |
| KJ-21020-PA16 | ELANTRA/LANTRA'00 | PA16/MT |
Structure Chart
| Brazed Radiator Structure | ||
| 1. Filler Neck | 8. Side Plate | 15. KINGA Logo |
| 2. Top Header Plate | 9. Core Height | 16. Bottom Header Plate |
| 3. Inlet Pipe | 10. Fin | 17. Water switch |
| 4. Top Tank | 11. Tube | 18. Bottom Tank |
| 5. Top Mounting Pins | 12. Core Width | 19. Oil Cooler |
| 6. Fan Mount | 13. Core Thickness | 20. Outlet Pipe |
| 7. Overflow Pipe | 14. Clip | |
Packing
Package design according to customer requirements.
NOTICE
1. Compare your radiator to the picture below
2. Flush the entire cooling system of the vehicle.
3. Use the astm-approved antifreeze and distilled or de-ionized water.
